Triumph Tiger User Manual

20
General Information
Speedometer and Odometer
The digital speedometer indicates the road
speed of the motorcycle. The read-out
displays the motorcycle road speed in
increments of one kilometre (or mile) per
hour.
The electronic odometer and two trip meters
are in the display screen. For details of the
operation of the odometer and trip meters,
please refer to the following pages.
Tachometer
The tachometer shows the engine speed in
revolutions per minute - rpm (r/min). At the
end of the tachometer range there is the
'red zone'. Engine rpm (r/min) in the red
zone is above maximum recommended
engine speed and is also above the range for
best performance.
Trip Computer
1. Display screen
2. Button A
To access the trip computer information press
and release button 'A' until the desired
display is visible. The display will scroll
through in the following order:
• Trip Meter 1
• Trip Meter 2
•Set up
Caution
Never allow engine rpm to enter the
'red zone' as severe engine damage may
result.
2
cfio_1
1

Triumph Tiger Specifications

General

Displacement	888 cc
Compression Ratio	11.27:1
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Gearbox	6-speed
Swingarm	Twin-sided, cast aluminium
Front Wheel	Cast aluminium, 19 x 2.5 in
Rear Wheel	Cast aluminium, 17 x 4.25 in
Front Tyre	100/90-19
Rear Tyre	150/70R17
Wet Weight	210 kg
Engine	Liquid-cooled, in-line 3-cylinder
Bore x Stroke	78.0 mm x 61.9 mm
Clutch	Wet, multi-plate
Frame	Tubular steel frame
Rear Brakes	Single 255 mm disc, ABS
Tank Capacity	20 L
Wheelbase	1, 555 mm
