Triumph XRX User Manual

Maintenance and Adjustment
147
Front fuse box
Rear fuse box
Note:
• The starter solenoid has an
additional 30 Amp fuse, attached
directly to the solenoid, beneath the
rider's seat.
Headlights
Circuit Protected Position Rating
(Amps)
Not used 6 -
Accessory sockets 5 15
Heated grips 4 5
Accessory lights 3 5
Auxiliary lighting 2 10
Cooling fan 1 15
Circuit Protected Position Rating
(Amps)
ABS 1 20
Fuel pump 2 10
Alarm, instruments, ECM 3 15
Engine management 4 20
Alarm, diagnostic
connector, instruments
510
Dip and main beam
headlights, starter relay
620
Warning
Adjust road speed to suit the visibility
and weather conditions in which the
motorcycle is being operated.
Ensure that the beams are adjusted
to illuminate the road surface
sufficiently far ahead without dazzling
oncoming traffic. An incorrectly
adjusted headlight may impair
visibility causing an accident.
Warning
Never attempt to adjust a headlight
beam when the motorcycle is in
motion.
Any attempt to adjust a headlight
beam when the motorcycle is in
motion may result in loss of
motorcycle control and an accident.
