OVERVIEW
Sample valve: Allowsforsamplingofrawwater.
Shut-off valve: Requiredtoallowmaintenanceofpre-treatmentequipment.
Pre-treatment (illustrative only):FortheUVsystemtooperateeffectively,thewatershouldmeetcertain
waterqualityparameters,asoutlinedbelow.Tomeetthese,pre-treatmentofthewatermayberequired.
Pre-treatmentequipmentmustbeinstalledBEFOREtheUVchamber.Pre-treatmentsystemscanbe
comprisedofoneormoreofthefollowingelements:sedimentfilters;carbonfilters;ironremovalsystems;
watersofteners;cystreductionfilters,etc.
Water Quality Requirements:
 Iron:  <.3PPM(.3mg/L)
 Hardness: <120PPM(7GrainsPerGallon)
 %UVT: >75%
1
2
3
4
5
Bypass shut-off valve: Bypasslineandvalveareoptional.Intendedtoprovideemergencywatersupplyin
theeventthattheUVsystemisunavailable.
Shut-off valve: RequiredtoallowmaintenanceofUVsystem.
Solenoid valve:OptionalpieceofequipmentsuppliedbyTrojan.Allowswatersupplytobeshut-offwhen
properdisinfectioncannotbeassured.
Note:Ifthegroundfromyourelectricalpanelistiedtoyourcopperwaterlines,andyouareusinga
solenoidvalve,installationofanapprovedgroundstrapisrequired.Thisgroundstrapwillmaintain
continuitybetweenthelinesthathavebeencuttoinstallthesolenoid.Checkyourlocalelectrical
codeforthecorrectclampandcablesize.
Sample valve:AllowsforsamplingofwaterenteringUVchamber;necessaryinordertoconfirmwater
beingtreatedisofadequatequality.
Plug kit: AstopperprovidedandinstalledbyTrojanonBasicmodels.
Sensor:MonitorsUVoutputtoensureproperdose(UVexposure)isbeingprovided.Uniquetestfunction
allowsverificationofsensorperformance.
UV chamber:Providesdisinfectionofthewater.MUSTBEINSTALLEDVERTICALLY.
CoolTouch
TM
fan:Removesexcessheatfromwaterinchamberduringperiodswithoutwaterflow.
Sample valve:AllowsforsamplingofwaterimmediatelyfollowingUVtreatment;necessaryinorderto
confirmproperoperationofUVsystem.
Shut-off valve: RequiredtoallowmaintenanceofUVsystem.
Power supply:PowersandcontrolstheUVlampandotherdevices.Provideshumaninterface,displaying
informationandallowingcontrolinputs(suchasmutingtheaudiblealarm).
Power source:Providespowertothepowersupply.Forsafetyreasonstheoutletmustbeprotectedby
aGroundFaultCircuitInterrupter(GFCI).NOTE:toprotectthepowersupply,aUL1449certified(or
equivalent)transientvoltagesurgesuppressorisrequired.
6
7
8
9
10
11
IMPORTANT:
A 5 micron (nominal) sediment filter must be installed
before the UV system and after any water softening equipment.
13
12
14
15
