INSTALLATION
OVERVIEW
WARRANTYMAINTENANCEOPERATION
INSTALLING THE UV SYSTEM
Determineappropriateindoorlocationof
thepowersupplyandchamber,referring
toDimensions and Layoutdrawing.
Powersupplyshouldbeinstalledhigher
thanchamberawayfromallwater
sources.Ensureadequateclearance
abovechambertoallowforremovalofthe
lampandsleeve.
Makeallnecessaryplumbingconnections.
Attachchamber
towallvertically.

Installscrews
apart:
Pro10:18.5"
Pro20:27.5"
Pro30:37.5"
4
1
3
2
10
WetO-ring
withwater
thenplace
overtopend
ofsleeve.
5
6
7
8
9
Donottouch
glasswith
barehands.
Insertcurved
endofsleeve
first.Donot
rotatesleeve.
Ensure
sleevebolt
isrotatedfull
1/4turnuntil
positivestop.
Ensure
sleevebolt
isrotatedfull
1/4turnuntil
positivestop.
WetO-ringwith
waterthenplace
overbottomend
ofsleeve.
Only
forPro
andPlus
Series.
1
2
1
2
1
2
9
