Trojan IGNITE 350 - Page 8

8
PARTS LIST
No. Description Qty
64 CKS Hex Screw 2
65 Washer 2
67 Base 1
68 Nut 2
69 Wheel (PBK 495215) 2
70 Truss Hex Screw (M8 x P1.25 x 40) (10 mm) 2
71 End Cap use with (Ø30 x 60 x 2.0T) 2
72 Foot Pad 4
73
Washer Drilling Philips Self Tapping Screw
(Ø4 x 20)
11
74 Incline Base 1
75 End Cap use with (Ø15 x 30 x 2.0T ) 4
76 Truss Hex Screw (M10 x P1.5 x 35) (10 mm) 4
77 Incline Base Flex-shaped Iron Plate Pin 2
78 R Pin (Ø10 x Ø2.0) 2
80 Flex Tube-Lower 1
81 POP - PIN Head 1
82 End Cap 1
83 Flex Tube - Upper 1
84 End cap (20 x 20 x 1.5T) 1
85 Cap 1
86 Round Head Philips Screw (M6 X P1.0 X 20) 1
88 Truss Hex Screw (M8 x P1.25 x 60) 2
89 Cylinder 1
90 Plastic Post Pad (PCAP 1721) 2
91 Plastic Washer (Ø8 x Ø22 x 6T) 6
92 Plastic Washer (Ø8.5 x Ø20 x 3.0T) 2
93 Left Upright 1
94 Right Upright 1
No. Description Qty
95
Truss Hex Screw (M8 x P1.25 x 40) (SAEK 242)
Round End
6
96 Console Tube 1
98 Foam Grip 2
99 Truss End Cap 2
100 Hand Pulse Set 2
101 Console 1
102 Safety Key 1
103
Truss Hex Screw (M8 x P1.25 x 25)
(SAE 812525) Round End and spiky
2
104 Truss Philips Screw (M5 x P0.8 x 20) 6
105 Truss Hex Screw (M8 x P1.25 x 15) 2
106 Cover 2
107 Hex Wrench 6 mm (80 mm x 80 mm) 1
108
Hex Wrench + Plus Driver 5mm (70 mm x
70 mm)
1
109 Silicon 1
111 Bottle 1
112 Left Decoration Cover 1
113 Right Decoration Cover 1
114 Foam Sticker 2
115 Round Head Philips Screw (M5 x P0.8 x 10) 2
116 Filter 1
117 Choke 1
120 Handrail Switch Plastic 2
121 Self Tapping Screw (Ø3 x 8) 2
122 Self Tapping Screw (Ø3 x 20) 4
123 Handrail Switch Decal (A) 1
124 Handrail Switch Decal (S) 1
125 Handrail Switch + Wire 2
