Trojan MULTIFUNTION SMITH MACHINE - Page 12

12
PARTS LIST
No. Description Qty
71 Buttery Cable 1
72 Low Cable 1
73 High Cable 1
74 Pulley Plate 2
75 Spacer (6 mm) 6
76 Large Washer (M10) 2
77 Button Bolt (M10 x 20 mm) 4
78 Locknut (M8) 8
79 Locknut (M10) 74
80 Round Cap (25 mm x 2 mm) 2
81 Chain 1
82 Self-tapping Screw (M4 x 19 mm) 16
83 Carriage Bolt (M10 x 65 mm) 10
84 Washer (M10) 64
85 Shoulder Bolt (M8 x 20 mm) 2
86 Washer (M6) 13
87 Screw (M6 x 70 mm) 6
88 Bolt (M10 x 63 mm) 2
89 Bolt (M10 x 90 mm) 7
90 Bolt (M10 x 68 mm) 10
91 Spring Collar 2
92 Bolt (M10 x 95 mm) 2
93 Split Washer (M10) 12
94 Washer (M8) 4
95 Button Screw (M10 x 30 mm) 2
96 Bolt (M10 x 45 mm) 11
97 Bolt (M10 x 93 mm) 12
98 Screw (M10 x 25 mm) 4
99 Bolt (M10 x 155 mm) 1
100 Locknut (M6) 5
101 Bolt (M10 x 115 mm) 2
102 Button Bolt (M10 x 75 mm) 6
103 Large Full Guard 2
104 Bolt (M10 x 50 mm) 5
105 Bolt (M10 x 75 mm) 2
106 Bolt (M10 x 81 mm) 1
107 Bench Frame 1
108 Bench Stabiliser 1
No. Description Qty
109 Front Leg 1
110 Leg Lever 1
111 Backrest Bracket 1
112 Curl Bar 1
113 Curl Post 1
114 Curl Pad 1
115 Long Pad Tube 1
116 Seat 1
117 Backrest 1
118 Backrest Frame 2
119 Square Cap (25 mm) 4
120 Cap (20 mm x 40 mm) 1
121 Screw (M6 x 40 mm) 2
122 Seat Frame 1
123 Seat Pin 1
124 Bench Knob 1
125 Curl Cap 1
126 Round Cap (25 mm x 1.5 mm) 2
127 Pad Cover 6
128 Foam Pad 6
129 Pad Tube 2
130 Bolt (M8 x 42 mm) 4
131 Square Cap (63.5 mm x 1.5 mm) 3
132 Square Cap (63.5 mm x 2 mm) 1
133 Square Cap (50 mm) 1
134 Buttery Bushing 4
135 Leg Bumper 1
136 Curl Post Knob 1
137 Bolt (M10 x 53 mm) 2
138 Thick Round Cap (48 mm) 3
139 Square Cap (57 mm) 2
140 Round Cap (19 mm) 6
142 Curl Bumper 1
142 Curl Pin 1
143 Carriage Bolt (M8 x 76 mm) 2
144 Bolt (M10 x 85 mm) 2
145 Bolt (M10 x 180 mm) 1
146 Screw (M6 x 45 mm) 4
