PRE ASSEMBLY CHECK LIST
Thank you for choosing the Trojan Multifunction Smith Machine. We take great pride in producing this product
and hope it will provide many hours of quality exercise to make you feel better, look better and enjoy life to
its fullest. Yes, it’s a proven fact that a regular exercise program can improve your physical and mental health.
Too often, our busy lifestyles limit our time and opportunity to exercise. The Trojan Multifunction Smith
Machine provides a convenient and simple method to begin your assault on getting your body in shape and
achieving a healthier lifestyle. Before reading further, please review the drawing below and familiarise yourself
with the parts that are labelled.
Read this manual carefully before using the Trojan Multifunction Smith Machine.
Set-up Size 2690 mm (l) x 2110 mm (w) x 2160 mm (h)
User Weight 200 kg (maximum)
Loading Weight 200 kg (maximum)
Note: The terms “right side” and “left side” are determined relative to a person sitting on the bench;
they do not correspond to right and left on the drawings in the manual.
RIGHT SIDE LEFT SIDE
Buttery Arm
Lat Bar
Handle
Weight Bar
Barbell Rest
Upright
Barbell Spotter
Backrest
Curl Pad
Seat
Curl bar
Leg Lever
Weight Carriage
Storage Tube
Foot Plate
Spotter
