HARDWARE & TOOLS LIST
INSTRUCTIONS FOR ASSEMBLY
• Before you start to assemble, please check the hardware packaging to make sure all parts are included.
• Each step has its own packet of bolts and nuts (look for sticker indicating what step the packet will be used for)
• Ensure all nuts and bolts are tightened properly before moving onto the next step.
• Basic tools, such as an Allen Key will be provided for assembly but additional tools will be required for complete
and safe assembly.
IMPORTANT NOTICE: Some of the smaller parts may be pre-tted to larger components, please ensure you check
carefully before contacting us regarding any missing parts.
TOOLS REQUIRED PERSONS REQUIRED INCLUDES
1. BASE
(2 PCS)
3. LEFT
UPRIGHT
(1 PC)
2. CENTRE BASE
(1 PC)
4. RIGHT
UPRIGHT
(1 PC)
5. WEIGHT
BAR GUIDE
(2 PCS)
6. LEFT
SUPPORT
(1 PC)
8. BACKREST
UPRIGHT
(1 PC)
7. RIGHT
SUPPORT
(1 PC)
9. FOOT PLATE
(1 PC)
10. LEFT ARM
(1 PC)
11. RIGHT ARM
(1 PC)
13. SIDE TOP FRAME
(2 PCS)
12. ARM FRAME
(1 PC)
14. CENTRE TOP FRAME
(1 PC)
15. SUPPORT FRAME
(2 PCS)
16. TOP FRAME
(1 PC)
18. LOCKING BAR
(1 PC)
17. WEIGHT BAR
(1 PC)
19. RIGHT CARRIAGE
(1 PC)
20. LEFT CARRIAGE
(1 PC)
2 X ADJUSTABLE
WRENCHES
RUBBER
MALLET
STANDARD
SCREWDRIVER
PHILLIPS
SCREWDRIVER
TapeGrease
