Trojan MULTIFUNTION SMITH MACHINE - Parts List

11
PARTS LIST
No. Description Qty
1 Base 2
2 Centre Base 1
3 Left Upright 1
4 Right Upright 1
5 Weight Bar Guide 2
6 Left Support 1
7 Right Support 1
8 Backrest Upright 1
9 Foot Plate 1
10 Left Arm 1
11 Right Arm 1
12 Arm Frame 1
13 Side Top Frame 2
14 Centre Top Frame 1
15 Support Frame 2
16 Top Frame 1
17 Weight Bar 1
18 Locking Bar 1
19 Right Carriage 1
20 Left Carriage 1
21 Screw (M8 x 20 mm) 1
22 Weight Bar Adapter 2
23 Weight Bar Bushing 2
24 Left Spotter 1
25 Right Spotter 1
26 Spotter Bushing 8
27 Carriage Bumper 6
28 Carriage Bushing 4
29 Upright Backrest 1
30 Arm Pad 2
31 Arm Bushing 4
32 Swivel Arm 2
33 Guide Cap 2
34 Screw (M6 x 20mm) 4
35 Barbell Rest 2
No. Description Qty
36 Barbell Spotter 2
37 Weight Bumper 4
38 Round Cap (48 mm) 4
39 Full Guard 4
40 Half Guard 22
41 Weight Carriage 1
42 Carriage Bushing 2
43 Ankle Strap 1
44 Spacer (50 mm) 1
45 Spacer (24 mm) 2
46 Double U-bracket 1
47 U-bracket 1
48 Handgrip 2
49 Cap (50 mm x 75 mm) 7
50 Stabiliser Foot 4
51 Large Base Foot 2
52 Cable Stop 4
53 Clip 4
54 Long Cable 1
55 Spacer (25 mm) 14
56 Bearing 4
57 Swivel Axle 2
58 Pulley (90 mm) 20
59 Pulley (115 mm) 3
60 V-pulley 2
61 Short Metal Cable Trap 2
62 Long Metal Cable Trap 2
63 Plastic Cable Trap 5
64 Carriage Guide 2
65 Lat Bar 1
66 Spacer (17 mm) 4
67 Handle 2
68 Snap Ring 2
69 Cable Clip 2
70 Cap (50 mm x 50 mm) 2
