Trojan MULTIFUNTION SMITH MACHINE - Page 50

50
4
3
18
17
25
24
17
4
3
ADJUSTMENTS AND ACCESSORIES
ADJUSTING THE SPOTTERS:
1. Before performing an exercise that uses the
Weight Bar (17), disengage the Spotters (24, 25)
from the Uprights (3, 4) and move them to the
lowest height to which you want the Weight Bar
to move.
2. Then, re-engage the Spotters at the desired
height.
USING THE WEIGHT BAR:
1. To use the Weight Bar (17), rst place the desired
amount of weight (not included) onto the ends
of the Weight Bar (see ADDING WEIGHT on
pg 51).
2. Then, disengage the Locking Bar (18) by rotating
it off the Uprights (3, 4).
3. When nished with the exercise, re-engage the
Locking Bar (18) by rotating it onto the Uprights
(3, 4).
ALWAYS SET BOTH SPOTTERS (24, 25)
AT THE SAME HEIGHT.
WARNING
3
3
17
17
18
25
24
4
4
ADJUSTMENTS AND ACCESSORIES
