HARDWARE & TOOLS LIST
56. BEARING
(4 PCS)
58. 90 MM PULLEY
(20 PCS)
57. SWIVEL AXLE
(2 PCS)
59. 115 MM PULLEY
(3 PCS)
60. V-PULLEY
(2 PCS)
61. SHORT METAL
CABLE TRAP (2 PCS)
63. PLASTIC CABLE TRAP
(5 PCS)
62. LONG METAL
CABLE TRAP (2 PCS)
64. CARRIAGE GUIDE
(2 PCS)
65. LAT BAR
(1 PC)
71. BUTTERFLY CABLE
(1 PC)
73. HIGH CABLE
(1 PC)
72. LOW CABLE
(1 PC)
74. PULLEY PLATE
(2 PCS)
75. 6 MM SPACER
(6 PCS)
81. CHAIN
(1 PC)
83. M10 X 65 MM CARRIAGE
BOLT (10 PCS)
82. M4 X 19 MM SELF-TAPPING
SCREW (16 PCS)
84. M10 WASHER (64 PCS) 85. M8 X 20 MM SHOULDER
BOLT (2 PCS)
66. 17 MM SPACER
(4 PCS)
68. SNAP RING
(2 PCS)
67. HANDLE
(2 PCS)
69. CABLE CLIP
(2 PCS)
70. 50 MM X 50 MM CAP
(2 PCS)
76. M10 LARGE WASHER
(2 PCS)
78. M8 LOCKNUT
(8 PCS)
77. M10 X 20MM
BUTTON BOLT (4 PCS)
79. M10 LOCKNUT
(74 PCS)
80. 25 MM X 2 MM
ROUND CAP (2 PCS)
86. M6 WASHER
(13 PCS)
88. M10 X 63 MM BOLT
(2 PCS)
87. M6 X 70 MM SCREW
(6 PCS)
89. M10 X 90 MM BOLT
(7 PCS)
90. M10 X 68 MM BOLT
(10 PCS)
