Trojan PACE 360 User Manual

10168-18
10. PARTS LIST
No. Qty. Description
37 1 Flywheel
38 1 Magnet
39 1 Reed Switch/Wire
40 1 M8x20mmBolt
41 8 M4x25mmRoundHeadScrew
42 8 M8 Split Washer
43 2 Flywheel Nut
44 1 Wing Knob Nut
45 1 Washer
46 4 M5x15mmRoundHeadScrew
47 1 M5x15mmScrew
48 6 M4x15mmScrew
49 1 M8 Nut
50 1 Handlebar
51 2 Pulse
52 1 Pulse Wire
53 1 Plug
54 1 Spacer
55 1pc CrankArm
56 1 Seat Knob
57 1 SeatBlock
58 1 SeatForwardandBackAdjustmentAssembly
59 2 Foam Grip
60 2 CrankCover
61 1 Resistance Cable
62 1 MotorBracket
63 7 M5x12mmScrew
64 1 Sensor Wire
65 2 LockWasher
66 2 Flange Nut
67 1 Decoration Cover
68 4 Curve Washer
69 1 Allen Wrench
70 1 Universal Wrench
1 User’s Manual
No. Qty. Description
1 1 Frame
2 1 FrontStabilizer
3 2 Pedal Strap
4 2 FrontStabilizerEndCap
5 1 Seat Post
6 1 RearStabilizer
7 2 Handlebar End Cap
8 2 RearStabilizerEndCap
9 1 QuickRelease
10 4 M8NylonLocknut
11 1 Idler
12 1 Seat
13 1 Upright
14 2 Clip
15 1 Adjust Washer
16 1 Consol
17 1 Left Side Shield
18 1 Right Side Shield
19 1 Resistance Motor/Cable
20 1 Seat Post Bushing
21 1 PulleyWithAxle
22 1 Reed Switch Clamp
23 1 ExtensionWire
24 1 Left Pedal
25 1 Spring
26 1 Right Pedal
27 2 3/8”Nut
28 2 U-Bracket
29 1 Lower Cable
30 4 M8 X 60mm Allen Head Screw
31 2 Eyebolt
32 2 M6NylonLocknut
33 2 M8 X 73mm Allen Head Screw
34 4 M8 X 15mm Button Screw
35 1 Belt
36 2 Bearing
