11.2 Operational sequences
The following details the main operational sequences of the XD One.
Primary function: STEL warning
Secondary function: Sequence function icon
Primary function: TWA warning
Secondary function: Sequence function icon
Primary function: Battery indication/heartbeat
Secondary function: Sequence function icon
Icon 1
Icon 2
Icon 3
11.1 User interface icons and indicators
