CONNECTIONS CONTINUED...
1. Power Connection:
Connect the plug-in power supply to the power (DC) connector.
2. Sensor connection:
Connect the RJ12 cable to the SENSORS connector and connect to a splitter on
the other end. Plug the 3-in-1 sensor to the splitter for connection. The other
connector on the splitter can be used to continuously connect to the next splitter.
Connect a CO2 sensor to the 2nd splitter. Repeat the procedure and connect
one or more smoke detector(s) if needed. Press the small button on the smoke
detector, the Hydro-X automatically assign an address to the unit sequentially.
3. Device Station Connection (main controller needs to be
powered on)
Connect the cable going from the DEVICES connector to the first Device Station
to be connected. Use the T-shape splitter and short RJ cable so that the first
cable can continue on to be connected to the next T-shape splitter (Device
Station) to be connected. Plug the Device Station to the wall outlet for power
supply. Press the small button on the device station, the system will
automatically assign an address to the device station in sequence. Repeat this
process until all device stations are connected to the main controller.
4. Light Connection
a ) For HID Lights
Connect the cable going from LINE 1 to the rst digital ballast to be connected.
Use the T-shape splitter and short RJ cable so that the first cable can continue
on to be connected to the next T-shape splitter (ballast) to be connected.Repeat
