1703CC, 1903CC, 2103CC • Owner’s Manual Supplement Chapter 10: Electrical System
1703 Battery System
1903 Battery System
NOTE: VIEW IS UNDERSIDE OF DECK
BATTERY
BATTERY
SWITCH
ENGINE
GROUND
GROUNDING
BLOCK
NEGATIVE
POSITIVE
NOTE: VIEW IS UNDERSIDE OF DECK
BATTERY
BATTERY
SWITCH
ENGINE
GROUND
GROUNDING
BLOCK
NEGATIVE
POSITIVE
