Chapter 2: Locations 1901 Bay Boat • Owner’s Manual Supplement
Helm
IGNITION
PANEL
AFT ACCESSORY SHIFT/THROTTLE
CONTROL
SEAWATER
WASHDOWN
FORWARD
BAITWELL
VHF RADIO
(IF EQUIPPED)
FISH FINDER
(IF EQUIPPED)
INSTRUMENT
LIGHTS
COURTESY
LIGHTS
TACHOMETER
SPEEDOMETER
FUEL
VOLTMETER
12-VOLT
DC OUTLET
BLANKNAVIGATION
LIGHTS
BILGE
PUMP
HORN
BAITWELL
MAY VARY DEPENDING ON ENGINE AND ACCESSORY OPTIONS.
NOTE: TYPICAL HELM LAYOUT SHOWN. ACTUAL LAYOUT
