1901 Bay Boat • Owner’s Manual Supplement
Chapter 6: Plumbing
Bilge Pump
• Your boat has a bilge
pump for pumping
water out of the bilge.
• An autofloat switch,
mounted next to the
bilge pump, will turn
On the bilge pump if
bilge water rises
above a preset level.
• You can also turn On
the bilge pump your-
self using the switch
at the helm.
• The bilge pump is
wired directly to the
battery. Unless the
battery is dead, the
bilge pump should
work even when your
boat is unattended.
NOTICE
Discharge of oil, oil waste, or fuel into navigable waters is prohibited by law. Violators are sub-
ject to legal action by the local authorities.
BILGE PUMP &
AUTOFLOAT SWITCH
THRU-HULL
DRAIN
