30
Chapter 6: Plumbing 1901 Bay Boat • Owner’s Manual Supplement
Baitwell System
Aft Baitwell Hull & Deck Views
FLOODING and SWAMPING HAZARD!
• NEVER leave your boat unattended while the baitwell system is running.
• Any leak or break in this system may allow large amounts of water to flood the bilge, which
could swamp the battery, and even sink your boat.
• Close the intake seacock when leaving your boat unattended for any length of time.
WARNING!
!
SYSTEM DAMAGE HAZARD!
BEFORE turning On the baitwell system, make sure the intake seacock is Open.
CAUTION
!
HULL ROUTING
SEAWATER INTAKE
SEACOCK
SEAWATER
INTAKE PUMP
AERATOR
NOTE: VIEW IS UNDERSIDE OF DECK
VENT
DECK ROUTING
DRAIN
SEACOCK
BAITWELL
TANK
OVERFLOW
DRAIN
FROM SEAWATER
INTAKE PUMP
TO BAITWELL
To Next Page
