Chapter 2: Locations 1901 Bay Boat • Owner’s Manual Supplement
Depth Finder Transducer (If Equipped):
Located on the transom.
Fuel Fill Deck Fitting
(marked GAS): Located on
the port deck.
Fuel Tank Fittings:
Access through the floor
deck plate forward of
the helm console.
Fuel Tank: Access
through the floor deck
plate forward of the
helm console.
TRANSDUCER
VENTED FUEL FILL
DECK FITTING
FUEL TANK
& FITTINGS
