Operating manual – Infrared camera
B - 4
02. COMPONENT GUIDE
Front
Back view
Controls / multifunction-dock port
Illuminator
Visual lens
IR lens
Laser Pointer
Definable trigger
Battery pack cover
Lens locker
Key pad
LCD display
Cancel
Power indicator
Auto adjust
Menu/Enter
Freeze/Saving
Power Switch
Battery cover locker
Power supply
USB 2.0
(optional)
miniSD card
Video output
