Operating manual – local air conditioner PAC 3500 E
Activities required before starting maintenance
Danger!
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
Danger!
Maintenance tasks which require the housing to be
opened must only be carried out by authorised
specialist companies or by Trotec.
Cleaning the housing
Clean the device with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Visual inspection of the inside of the device for dirt
1. Remove the air filter.
2. Use a torch to illuminate the openings of the device.
3. Check the inside of the device for dirt.
4. If you see a thick layer of dust, have the inside of the device
cleaned by a specialist company for cooling and air-
conditioning or by Trotec.
5. Put the air filter back in.
Cleaning the air filter
The EVA air filter and the CON air filter must be cleaned as soon
as they are dirty. This is brought to light e.g. by a reduced
capacity (see chapter Errors and faults).
Caution!
Ensure that the air filter is not worn or damaged. The
corners and edges of the air filter must not be
deformed or rounded. Before reinserting the air filter,
make sure that it is undamaged and dry!
1. Remove the EVA air filter and the CON air filter from the
device.
2. Clean the EVA air filter and the CON air filter with a slightly
damp, soft, lint-free cloth. If the filter is heavily
contaminated, clean it with warm water mixed with a
neutral cleaning agent.
3. Allow the EVA air filter and the CON air filter to dry
completely. Do NOT insert a wet filter into the device!
4. Reinsert the EVA air filter and the CON air filter into the
device.
