Operating manual – convector TCH 20 E / TCH 22 E
Maintenance
Activities required before starting maintenance
Warning of electrical voltage
Do not touch the mains plug with wet or damp hands.
• Switch the device off.
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Allow the device to cool down completely.
Warning of electrical voltage
Tasks which require the housing to be opened
must only be carried out by authorised specialist
companies or by Trotec.
Cleaning the housing
Warning of electrical voltage
Never immerse the device in water!
Clean the housing with a soft, damp and lint-free cloth. Ensure
that no moisture enters the housing. Protect electrical
components from moisture. Do not use any aggressive cleaning
agents such as cleaning sprays, solvents, alcohol-based or
abrasive cleaners to dampen the cloth.
Wipe the housing dry after cleaning.
Technical annex
Technical data
Parameter Value
Model TCH 20 E TCH 22 E
Heating capacity
level1:
level2:
level3:
750 W
1250 W
2000 W
750 W
1250 W
2000 W
Mains connection 230V/ 50Hz 230V/ 50Hz
Power consumption
max.
2000 W 2000 W
Nominal current
consumption
8.7 A 8.7 A
Fusing 10 A 10 A
Plug type Schuko plug
CEE 7/7
Schuko plug
CEE 7/7
Cable length 1.2 m 1.2 m
Dimensions (depth x
width x height)
110 x 520 x
340 mm
110 x 510 x
340 mm
Minimum distance to
walls and other
objects
top (A):
rear (B):
sides (C):
front (D):
50 cm
50 cm
50 cm
50 cm
50 cm
50 cm
50 cm
50 cm
Weight 2.0 kg 2.5 kg
