EN 13
garden pump TGP 1025 E
5. Use an air gauge to check the precharge pressure at the
pressure tank valve(7). It should be 1.5 to 1.8bar.
6. If necessary, adjust the pressure by pumping in or
releasing air.
7. Screw the protective cap back onto the pressure tank
valve(7).
Safety signs and labels on the device
Check the safety signs and labels attached to the device at
regular intervals. Replace illegible safety signs!
Cleaning
• Clean the device with a soft, damp and lint-free cloth.
Protect electrical components from moisture. Do not use
any aggressive cleaning agents such as cleaning sprays,
solvents, alcohol-based or abrasive cleaners to dampen
the cloth.
• Rinse the inside of the device with clear, lukewarm water.
Technical annex
Technical data
Parameter Value
Model TGP1025E
Max. feed rate 3300l/h
Max. pump height 30m
Max. suction height 7m
Max. air pressure 3 bar
Automatic switch-on 1.5 bar
Automatic switch-off 3 bar
Pressure tank 19l
Max. water temperature 35°C
Thermal overload protection 150°C
Power supply 230V ~ 50Hz
Power input 1000W
Protection type of the pump IPX4
Protection type of the mains
plug
IP44
Connection type CEE 7/7
Cable length 1.2m
Protection class I
Weight 10.5kg
Dimensions
(lengthx widthx height)
270x 453x 500(mm)
Max. particle size 2mm
Pressure connection 1" internal thread
Suction connection 1" internal thread
Sound values according to EN ISO 3744:1995
Sound pressure level L
pA
72dB(A)
Sound power level L
WA
88dB(A)
Uncertainty K
WA
2dB(A)
