EN 7
garden pump TGP 1025 E
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Before transporting the device, observe the following:
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not carry the device by holding it at the power supply
cable or hose.
Storage
When the device is not being used, observe the following
storage conditions:
• dry and protected from frost and heat
• in an upright position where it is protected from dust and
direct sunlight
• with a cover to protect it from invasive dust, if necessary
• Check whether there is residual water left in the device,
and drain any residual water via the water drain nozzle(5)
to prevent rust formation.
• Put the protective caps on the pressure and suction
connection to protect the inside of the device against dust
and dirt.
If you do not use the device for an extended period of time, it
must be cleaned thoroughly after its last application and before
recommissioning. Deposits and residues could lead to start-up
difficulties.
For restart, please proceed according to the Start-up chapter.
Assembly and installation
Scope of delivery
• 1x Garden pump
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
Start-up
Positioning
Warning of electrical voltage
Do not position the device in damp shafts. There is risk
of short circuit!
Note
Positioning the device in damp shafts can result in
damage to the device caused by corrosion!
Select a suitable location for positioning the device. It should
meet the following criteria:
• The site of installation is protected from weather exposure
and wet conditions.
• The surface is horizontal and level.
• The site of installation can support the weight of the device
and the pumped media.
For a permanent installation, the feet(8) of the device can be
bolted to the ground.
Connecting the pipe or hose line
The device may be operated using either a hose line or a pipe.
Ex factory, the device is delivered with a 1" internal thread.
Please note the following:
• The device cannot be moved flexibly when using a solid
pipe.
• Use a pressure line and suction line with a diameter
corresponding to the size of the connections or above.
A smaller diameter causes pressure loss and thus reduces
the feed rate.
• The smaller the pump height of the pressure line and
suction line, the higher the feed rate.
• Connected accessories can cause a pressure loss and
reduce the feed rate.
