Trotec TGP 1025 E - Filling and Operation; Filling the Device with Water

EN 9
garden pump TGP 1025 E
Note
Keep the protective cap of the suction connection so
you can use it when storing the device to protect the
inside of the device against dust and dirt.
2. Connect the suction line to the suction connection(4).
3. Submerge the intake opening of the suction line at the
point of withdrawal, and make sure the intake opening is
always sufficiently covered with water.
Note
Make sure that the suction line is always installed with
an upward incline. Otherwise, an air bubble may form
at higher parts of the suction line and make the device
run dry.
Note
At the bottom of ponds and other waterbodies deposits
may have accumulated over time. To prevent the
device from being damaged, do not lower the suction
line all the way to the ground. Alternatively, you may
also connect a suitable pre-filter with backflow
preventer to the suction line.
Filling the device with water
Warning of electrical voltage
There is a risk of electric shock when filling the device
with water.
Before filling the device, always make sure that the
mains plug has been removed.
1. Open the screw plug at the water filler neck(3).
3
2. Fill the device with the pumping medium all the way to the
edge via the water filler neck(3). The connected suction
line should also be completely filled with the pumping
medium.
3. Screw the screw plug back onto the water filler neck(3).
Ensure a tight fit of the screw plug.
