dehumidifier TTK 100 E
No. Spare Part No. Spare Part No. Spare Part
1 BASE PAN 16 CAPILLARY TUBE 31 SIDE PLATE
2 TURING WHEEL ASS'Y 17 FIX TURE 32 SIDE PLATE
3 COMPRESSOR ASS'Y (35D039-D1) 18 FAN MOTOR(YDK-08001304-WJ45) 33 PEAR PANEL
4 RUBBER 19 FAN CASING 34 HANDLE
5 SUCTION PIPE 20 BLOWER WHEEL 35 FRONT PANEL
6 DISCHARGE PIPE 21 SCREEN 36 CONTROL PLATE
7 PLATE 22 CAPACITOR(1.5uF/450V)(FOR FAN
MOTOR(18))
37 CONTROL PANEL
8 CAPACITOR (10uF/450V)(FOR
COMPRESSOR(3))
23 POWER SUPPLY CORD COMPLETE 38 INTAKE GRILLE
9 FIX METAL 24 FIX TURE 39 TANK LID
10 SENSOR (FOR EVA) 25 COVER 40 FIX TUBE
11 REED SWITCH 26 CONTROL BOARD 41 DRAIN BUCKET
12 DRAINAGE PAN 27 PC BOARD(FOR EVA ) 42 2-WAY REVERSING VSLVE ASS'Y
13 EVAPORATOR ASS'Y 28 SENSOR 43 COVER
14 CONDENSER ASS'Y 29 FIX TURE
15 Y TUBE 30 FIX METAL
Disposal
The icon with the crossed-out waste bin on waste
electrical or electronic equipment stipulates that this equipment
must not be disposed of with the household waste at the end of
its life. You will find collection points for free return of waste
electrical and electronic equipment in your vicinity. The
addresses can be obtained from your municipality or local
administration. You can also find out about other return options
that apply for many EU countries on the website
https://hub.trotec.com/?id=45090. Otherwise, please contact an
official recycling centre for electronic and electrical equipment
authorised for your country.
The separate collection of waste electrical and electronic
equipment aims to enable the re-use, recycling and other forms
of recovery of waste equipment as well as to prevent negative
effects for the environment and human health caused by the
disposal of hazardous substances potentially contained in the
equipment.
Have the refrigerant (propane) disposed of appropriately and
according to the national regulations by a company with the
relevant certification (European Waste Catalogue 160504).
