16 EN
dehumidifier TTK 100 E
3. Rinse the condensation tank with clear water. Regularly
clean the condensation tank using a mild cleaning agent
(no detergent!).
4. Refit the condensation tank into the device.
Make sure not to damage the float when inserting or
removing the condensation tank.
In doing so, make sure that the float is positioned
correctly.
In doing so, make sure that the condensation tank is
inserted correctly, for otherwise the device cannot be
switched back on.
Activities required after maintenance
If you want to continue using the device:
• Leave the device to rest for 12to24hours, so the
refrigerant can accumulate within the compressor. Wait
12to24hours before switching the device back on! Acting
contrary might lead to compressor damage and a
malfunctioning device. If so, any warranty claims will be
voided.
• Reconnect the device to the mains.
If you do not intend to use the device for a considerable time:
• Store the device according to the Transport and storage
chapter.
Technical annex
Technical data
Parameter Value
Model TTK100E
Dehumidifying capacity, max. 30l / 24 h
Air flow rate 215m
3
/h
Operating range (temperature) 5°C to 32°C
Operating range
(relative humidity)
30% to 80%RH
Pressure suction side 1.2MPa
Pressure outlet side 2.4MPa
Max. permissible pressure 2.6MPa
Mains connection 220–240V/ 50Hz
Max. power input 0.57kW
Nominal current 2.4A
Refrigerant R290
Amount of refrigerant 122g
GWP factor 3
CO
2
equivalent 0.000366t
Water tank 4.3l
Sound pressure level
(at a distance of 1m)
50dB(A)
Dimensions
(lengthx widthx height)
274 x 390 x 612mm
Minimum distance to walls and
other objects
A: top:
B: rear:
C: side:
D: front:
50cm
50cm
50cm
50cm
Weight 15.5kg
