EN Operating Manual – Dehumidifier TTK 25 E B - 3
Technical data
Circuit diagram
Parameters Values
Model TTK 25 E
Dehumidifying capacity, max. 12 l / 24 h
Operating temperature 5-35 °C
Working range for relative humidity 30-100 %
Volume of airflow, max. 49.8 m³/h
Electric connection 230 V / 50 Hz
Power consumption, max. 205 W
Fuse (home) 10 A
Condensation tank 1.9 l
Refrigerant R134a
Amount of refrigerant 110 g
Weight 8.5 kg
Dimensions (HxDxW) 386 x 230 x 230 mm
Minimum distance from walls of other objects A: Above: 45 cm
B: Behind: 45 cm
C: Side: 45 cm
D: Front: 45 cm
Sound pressure level LpA (1 m; complies with DIN 45635-01-KL3) 43 dB(A)
