Trotec TTK 53 E - Technical Annex; Technical Data

EN 17
dehumidifier TTK 53 E / TTK 72 E
Technical annex
Technical data
Parameter Value
Model TTK53E TTK72E
Max. dehumidification performance 16l / 24 h 24l / 24 h
Air flow rate 195 m
3
/h 195 m
3
/h
Operating range (temperature) 5 °C to 32 °C 5 °C to 32 °C
Operating range (relative humidity) 30% to 80% RH 30% to 80% RH
Pressure suction side 1.2MPa 1.2MPa
Pressure outlet side 2.5MPa 2.5MPa
Mains supply 220-240V/ 50Hz 220-240V/ 50Hz
Max. power consumption 0.24kW 0.32kW
Nominal current 1.04A 1.48A
Type of protection IPX2 IPX2
Fusing
T3.15A / 250 V AC T3.15A / 250 V AC
Refrigerant R290 R290
Amount of refrigerant 55g 60g
GWP factor 3 3
CO
2
equivalent 0.000165t 0.00018t
Water tank 5.5 l 5.5 l
Sound pressure level 48 dB(A) 48 dB(A)
Dimensions (lengthx widthx height) 185 x 330x 550mm 198 x 330x 570mm
Minimum distance to walls and other objects
A: top:
B: rear:
C: side:
D: front:
30 cm
20 cm
20 cm
10 cm
30 cm
20 cm
20 cm
10 cm
Weight 12kg 13kg
