EN 15
dehumidifier TTK 65 E
4. Refit the condensation tank into the device.
Make sure not to damage the float when inserting or
removing the condensation tank.
In doing so, make sure that the float is positioned
correctly.
In doing so, make sure that the condensation tank is
inserted correctly, for otherwise the device cannot be
switched back on.
Activities required after maintenance
If you want to continue using the device:
• Leave the device to rest for 12to24hours, so the
refrigerant can accumulate within the compressor. Wait
12to24hours before switching the device back on! Acting
contrary might lead to compressor damage and a
malfunctioning device. If so, any warranty claims will be
voided.
• Reconnect the device to the mains.
If you do not intend to use the device for a considerable time:
• Store the device according to the Storage chapter.
Technical annex
Technical data
Parameter Value
Model TTK65E
Max. dehumidification performance 20 l / 24 h
Air flow rate 180 m
3
/h
Operating range (temperature) 5°C to 35°C
Operating range (relative humidity) 30% to 80%RH
Pressure suction side 0.6MPa
Pressure outlet side 1.7MPa
Mains supply 230V/ 50Hz
Power consumption max. 0.33 kW
Nominal current 2 A
Refrigerant R-134a
Amount of refrigerant 200 g
GWP factor 1,430
CO
2
equivalent 0.286 t
Water tank 4 l
Sound pressure level
(at a distance of 1m)
45 dB(A)
Dimensions (lengthx widthx height) 262x 343x 525 mm
Minimum distance to walls and other
objects
A: top
B: rear
C: side
D: front
100 cm
100 cm
100 cm
100 cm
Weight 15.5 kg
