Trotec ttk 71 e - Technical Annex

EN 17
dehumidifier TTK 71 E
Technical annex
Technical data
Parameter Value
Model TTK71E
Dehumidifying capacity, max. 24l / 24 h
Air flow rate 180m
3
/h
Operating range (temperature) 5°C to 32°C
Operating range (relative
humidity)
30% to 90%RH
Pressure suction side 1.2MPa
Pressure outlet side 2.5MPa
Max. permissible pressure 2.5MPa
Mains supply 220 – 240V ~ 50 Hz
Max. power input 0.42W
Nominal current 1.8A
Refrigerant R290
Amount of refrigerant 55g
GWP factor 3
CO
2
equivalent 0.000165t
Water tank 2.3l
Sound pressure level 48dB(A)
Dimensions (lengthx widthx
height)
220x 350x 550mm
Minimum distance to walls and
other objects
A: top:
B: rear:
C: side:
D: front:
30cm
20cm
20cm
10cm
Weight 13kg
