EN 7
submerged clear water pump, near-ground suction TWP 4006 E / TWP 7506 E
Transport and storage
Note
If you store or transport the device improperly, the
device may be damaged.
Note the information regarding transport and storage of
the device.
Transport
Before transporting the device, observe the following:
• Hold onto the mains plug while pulling the power cable out
of the mains socket.
• Do not use the power cable to drag the device.
• Only carry the device by the transport handle.
• Do not carry the device by holding it at the power cable or
hose.
Storage
When the device is not being used, observe the following
storage conditions:
• Dry and protected from frost and heat
• In an upright position where it is protected from dust and
direct sunlight
• With a cover to protect it from invasive dust, if necessary
• Place no further devices or objects on top of the device to
prevent it from being damaged.
If you do not use the device for an extended period of time, it
must be cleaned thoroughly after its last application and before
recommissioning. Deposits and residues could lead to start-up
difficulties.
For restart, please proceed according to the Start-up chapter.
Assembly and installation
Scope of delivery
• 1x Submerged clear water pump
• 1x Reducer for hoses with inner diameters of 25mm or
38mm as well as hose connections withG1"/DN25
internal thread
• 1x elbow for hose connections with G1½"/ DN40 internal
thread
• 1x Backflow preventer (pre-installed)
• 1x Stainless steel washer (pre-installed)
• 1x Nylon cord (10m)
• 1x Manual
Unpacking the device
1. Open the cardboard box and take the device out.
2. Completely remove the packaging.
3. Fully unwind the power cable. Make sure that the power
cable is not damaged and that you do not damage it during
unwinding.
Start-up
Connecting the pipe or hose line
The device may be operated using either a hose line or a pipe.
Ex factory, the device is delivered with a connection for the
"Quick Connect" connection system.
Please observe the following information regarding water
discharge:
• Please note that making use of the reducer(7) might
decrease the device performance. The reducer should be
shortened to the used diameter so as not to affect the
device performance.
• Please note that the device cannot be moved as flexibly
when using a solid pipe.
• Note that the maximum particle size is reduced according
to the hose diameter.
• Please note that the conveying capacity declines with an
increasing length of the water discharge line.
Info
If required, you can cut the reducer(7) off at the
desired diameter.
At delivery the reducer(7) is already assembled with
the backflow preventer(8) and stainless steel
washer(9) onto the elbow(10).
