Troxler 3400-B Series User Manual

Appendix A-14
10245 and 10256 and after)
103276 HV Power Supply Assembly (1000 V)
102116
Indexer Assembly 3400 (before SN 10256
except 10245)
103021
LCD
012185
Lock with 2 Keys (H-1209)
012176 Lock with two keys (SN before 14410)
103397
Moisture PreAmp 6.5V Module
103787 Plunger 3400 (Indexer for SN 10245-14409)
104553
Plunger 3400 (Indexer for SN 10245-14409)
104639
HV Power Supply Assembly
102847 Processor (Complete) 3411-B
012753
Ring, Retaining (2 required)
101604.1610 Roll Pin 1/8 Dia X 1" (Trigger)
102140
Seal Retainer 3400
012752 Seal Wiper, Source Rod (SN before 12623)
012751 Seal, Source Rod Bearing (T. S-625)
102399
Shield Spring 3400
012200 Spring (SN 10245 and 10256 and above)
102075
Top Shell 3400
102069.1000 Wiper Cap, Source Rod (after SN 12623)
102069
Wiper Cap, 2400/3400

Troxler 3400-B Series Specifications

General

Brand	Troxler
Model	3400-B Series
Category	Measuring Instruments
Language	English
