Safety Rules
TABLE OF CONTENTS
SafetyRules.................................. 2-4
Know Your Generator ........................... 5
Assembly.................................... 6-7
Operation .................................. 8-II
Maintenance.................................. 12
Storage...................................... 13
Troubleshooting ............................... 14
Notes .................................. 15& 23
Schematic/Wiring Diagram .................... 16-17
Replacement Parts........................... 18-22
Warranty ............................... Last Page
EQUIPMENT
DESCRIPTION
_Read this manual carefully and become
familiar with your generator. Know its
applications, its limitations and any hazards
involved.
This manualdescribes an engine-driven, revolving field,
alternating current (AC) generator designedto supply
electrical power for operating compatible electrical lighting,
appliances,tools and motor loads.Thegenerator's revolving
field is driven at about 3,600rpm by a single-cylinder engine.
CAUTION! DO NOT exceed the generator's
wattage/amperage capacity.See"Don't Overload
Generator" on page I h
Everyeffort hasbeenmadeto ensure that informationinthis
manualisaccurateand current. However,we reserve the
right to change,alter or otherwise improvethe product and
this document at anytime without prior notice.
The EmissionControl Systemfor this generator iswarranted
for standardsset by the EnvironmentalProtection Agency.For
warranty informationrefer to the engineowner's manual.
SAFETY RULES
_ his is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
The safety alert symbol (_.) isused with a signalword
(DANGER, CAUTION,WARNING), a pictorial and/or a
safety messageto alert you to hazards.DANGER indicates
a hazard which, if not avoided,will result in death or serious
injury.WARNING indicatesa hazardwhich,if not avoided,
couldresult in death or serious injury.CAUTION
indicatesa hazardwhich, if not avoided,might result in
minor or moderate injury.CAUTION, when used
without the alert symbol, indicatesa situation that could
result in equipment damage.Follow safety messagesto
avoid or reduce the risk of injuryor death.
In the State of California a spark arrester isrequired by law
(Section 4442 of the California Public ResourcesCode).
Other states may havesimilar laws.Federallawsapplyon
federal lands.If you equip the muffler with a spark arrester,
it must be maintained in effectiveworking order.
WARNING
The engine exhaust from this product contains I
chemicals known to the State of California to cause
cancer, b rth defects, or other reproduct ve harm.
