19
Ref.
No
Part No. Description
1. 710-0599 TT Screw 1/4-20 x 0.5
2. 736-0270 Bell Washer.265 x 0.75
3. 17032A Deflector Chute Adapter
4. 732-1014 Torsion Spring
5. 747-0710 Hinge Pin
6. 710-0654A Self-Tapping Sems Screw
7. 787-01222 21” Deck
8. 710-0216 Hex Screw 3/8-16 x.75
9. 712-0431 Hex Nut 3/8-16
10. 782-5002B Front Baffle
11. 750-04404 Sleeve Spacer 9.10” Lg.
12. 750-04405 Slev. Spacer 1.5” Lg.
13. 734-04018A Wheel 8 x 2.125 Gear
14. 716-0865 Snap Ring
15. 717-1762 Gear 14T RH FWD
717-1761 Gear 14T LH FWD *
16. 782-7551A Wheel Dust Cap
17. 716-0102 Snap Ring
18. 736-0474 Washer
19. 687-02018 Lever Assembly RH
20. 687-02044 Pivot Plate Assembly
21. 782-0512B Height Adjuster Plate - RH
782-0511A Height Adjuster Plate - LH*
22. 736-0447 Wave Washer
23. 748-0355 Bearing Support
24. 741-0604A Bearing Sleeve
25. 732-0708 Bearing Retainer
26. 687-02057 Handle Bracket Assembly - LH
687-02056 Handle Bracket Assembly - RH*
27. 687-02033 Handle Bracket - RH
687-02031 Handle Bracket - LH*
28. 687-02039 Pivot Bar RH
687-02040 Pivot Bar LH*
29. 732-0866 Height Adjustment Lever
30. 720-0312 Foam Grip
31. 738-0507B Shoulder Scr.500 Dia. x.434
32. 710-1652 Tt Screw 1/4-20 x.625”
33. 734-04127 Wheel, 12 x 2.125
34. 715-0221 Dowel Pin
35. 712-0116 Hex Jam Nut 5/16-24
36. 736-0105 Bell Washer.325 x.930 x.45
37. 756-04132 Pulley, 3.82 x.313 x.68
38. 732-04273 Compression Spring
39. 711-04317 Pinion Shaft
40. 731-05099 Upper Housing
41. 731-04883 Lower Housing
42. 710-04329 Torx Screw
43. 711-04304 Output Shaft
44. 682-0511A Height Adjustment Assembly LH
682-0512A Height Adjustment Assembly RH*
45. 618-04274 Transmission Assembly Comp.*
46. 720-0426 Adjustment Knob
47. 732-0706 Front Lever RH
732-0707 Front Lever LH*
48. 712-3005 Hex Flange Lock Nut 3/8-16
49. 707-04409 Shifter Fork
50. 707-04567 Transmission Bracket
51. 717-04194 28 Tooth Gear
52. 715-0129 Spirol Pin
53. 415-04030 Dowel Pin
54. 726-04043 Push Nut
55. 731-05187 Clutch Lever
56. 736-04178 Slotted Washer
57. 721-04110 O-ring
58.‘ 736-04170 Flat Washer
59. 721-04107 Oil Seal
60. 741-04116 Ball Bearing
61. 710-04374 Hex Screw
62. 741-04106 Plastic Bushing
63. 436-0572 Flat Washer
Ref.
No
Part No. Description
Model Series 566 & 569
*Not Pictured in Illustration
