Troy-Bilt 7524 - Page 23

23
Style Q
REF.
NO.
PART
NO. DESCRIPTION
1 631-04127 Panel Assembly, Handle, Q-Style
(Inc. Ref. 47)
2 631-04133 Handle Assembly, Clutch Lock, LH
(Inc. Ref. 48)
3 631-04134 Handle Assembly, Clutch Lock, RH
(Inc. Ref. 48)
4 684-04105 Handle Assembly, Engagement, LH
5 684-04106 Handle Assembly, Engagement, RH
6 710-04326 Screw, #8-16 x .50
7 710-04354 Screw, 1/4-20 x .375
8 710-1026 Screw, Self-tapping, 1/4-20 x 1.750
9 710-1233 Screw, Machine, #10-24 x 1.375
10 711-04287 Rod, Pivot
11 711-0677 Ferrule, 5/16-18 x .312
12 712-04064 Nut, Flange Lock, Nylon, 1/4-20
13 712-04081A Nut, Shoulder, Hex, 1/4-20,
14 714-0104 Pin, Cotter, .072 Dia. x 1.13
15 720-0274 Grip, 1.0 ID x 5.0
16 720-04039 Knob, Shift
17 725-04213 Lamp
18 725-04214 Harness, Headlight
19 725-1649 Socket, Lamp
20 726-0470 Tie, Cable, 19 x 8.39”, Tree Mount
21 731-04894 Plate, Lock
22 731-04896 Cam, Clutch Lock
23 732-0193 Spring, Compression, .39 x .60 x .88
24 732-04219 Spring, Clutch, Lock
25 732-04238 Spring, Torsion, 0.8156 ID x .3038
26 735-0199A Bumper, Rubber, .62 OD x .22
27 736-0262 Washer, Flat, .385 x .870 x .092
28 738-04122 Screw, Shoulder, .437 x 1.345, 1/4-20
29 738-04125 Screw, Shoulder, .374 Dia. x 1.05
30 746-0778 Z-Fitting, Cable
31 747-04348 Rod, Shift, .312 x 8.98 Upper
32 750-0963 Connector Sleeve, Shift Rod
33 790-00130 Lever, Shift
34 790-00140 Bracket, Panel
35 710-0449 Screw, Carriage, 5/16-18, 2.25, Gr5
36 710-0726 Screw, 5/16-12, 0.750
37 720-0284 Wing Knob, 5/16-18
38 736-0451 Washer, Saddle, 320 x .93 x .060
39 749-04138 Handle, Lower, Snow
40 749-04141 Handle, Upper, RH
41 749-04142 Handle, Upper, LH
42 712-04063 Nut, Flange Lock, Nylon, 5/16-18
43 726-0135 Nut, Speed, .3125 Dia.
44 732-04205 Spring Lever, Shift
45 790-00156 Bracket, Shift Spacer
46 747-04257 Shift Rod, Lower
47 731-04885 Lens
48 712-0161 Nut, Hex Lock, Nylon, #10-24, Gr2
49 684-04116 Chute Control Assembly, 4-Way (Inc.
Cables & Control Head, not shown)
50 790-00131 Bracket, Joystick
51 710-04187 Screw, 1/4-15 x .50
52 712-04082 Nut, Hex Lock, 1/4-20
53 738-04133 Bolt, Shoulder, 5/16 x 1.7, 1/4-20
54 753-04864 Kit, Chute Control Housing
55 753-04866 Kit, Lever Tube
56 753-04863 Kit. 4-Way Knob
57 736-0463 Washer, Flat, .25 x .630 x .051
REF.
NO.
PART
NO. DESCRIPTION
