15
REF
NO.
PART No. DESCRIPTION Qty.
1 629-0071 Extension Cord 1
2 710-0409 Hex Screw, 5/16-24 x 1.75 4
3 710-0627 Hex Screw, 5/16-24 x .75 1
4 710-0654A Self Tapping Screw, 3/8-16 x 1 2
5 710-0751 Hex Screw, 1/4-20 x .62 1
6 710-1003 Screw, #10-16 x .625 2
7 712-04064 Hex Flange Lock Nut, 1/4-20 9
8 726-0154 Push Mount Cable Tie 1
9 726-0201 Speed Nut, .3125 4
10 726-0205 Clamp, Hose 2
11 731-2825 Knob, Choke 1
12 736-0119 Washer, Lock 5/16 4
13 736-0159 Flat Washer .349 x .879 x .063 1
14 747-04236 Gas Tank Support Wire 1
15 750-04297 Spacer, Engine 4
16 751-0535 Hose, Fuel Line 18
17 751-10023 Tank, Fuel 1
18 751-10278 Cap, Fuel 1
19 754-0101A V-Belt, 1/2 1
20 756-0416B Pulley Half, .625 ID x 2.25 OD 2
21 756-0475 Pulley, 1/2 V 1/2-20 LH x 6.0 1
22 790-00216 Bracket, Engine 1
23 790-00134 Bracket Support Gas Tank 1
24 7511152847 Primer Hose Line 4
25 7512B1476 Primer 1
26 734-04063 Wheel, 7 x 1.5 Star Gray 2
27 684-04168 Idler Pulley (Pulley hole 1/4”) 1
28 735-04033 Rubber Paddle 2
9
For parts and/or
accessories
please call
1-866-840-6483, or
1-330-558-7220.
www.troybilt.com
Part List:
Snow
Thrower
REF
NO.
PART No. DESCRIPTION Qty.
29 710-0896 Hex Screw, 1/4-20 x .62 24
30 735-04032 Cresent Spiral 4
31 684-04025A Auger Axle 1
32 710-0642 Hex Screw 1/4-20 x .75 Gr. 5 1
33 710-0653 Self-tapping Screw 1/4-20 x .375 1
34 712-0896 Hex Lock Nut 1/4-28 1
35 710-1005 Self-tapping Screw, 1/4-14 x .50” 6
36 712-04063 Hex Flange Lock Nut, 5/16-18 1
37 726-0299 Push Cap, 1/2” 2
38 736-0326 Flat Washer .510 x 1.00 x .125 1
39 736-0329 Lock Washer, 1/4 1
40 736-0176 Flat Washer .265 x .938 x .120 1
41 741-0600 Ball Bearing 17 x 40 x 12 2
42 684-04167 Auger Assembly Housing 1
43 748-0234 Shoulder Spacer .25 1
44 738-0924 Carriage Screw 1/4-28 1
45 784-5174 Bearing Cup 2
46 790-00238A Idler Brkt. w/Brake (Pulley hole 1/4”) 1
47 790-00045 Belt Cover 1
48 710-0106 Hex Screw, 3/8-24 x 1.25 1
49 756-0625 Cable Roller 1
50 684-04027A Auger Assembly 1
51 790-00238 Idler Brkt. w/ Brake (Pulley hole 3/8”) 1
52 756-0313 Idler Pulley (3/8” hole) 1
53 710-0191 Hex Screw 3/8-24 x 1.25 1
54 712-0116 Jam Lock Nut 3/8--24 1
55 722-3022 Foam Tape .625 x .25 2
NOTES: For a proper working machine,
use Factory Approved Parts. V-belts are
designed to engage and disengage safely.
A substitute (non OEM) V-belt can be
dangerous by not disengaging completely.
NOTE: Snow thrower features/components vary by model. NOT all parts listed above and pictured on the previous
page are standard equipment.
