17
9
REF
NO.
PART NUMBER DESCRIPTION Qty.
1 684-04127 Chute Assembly 1
2 710-04071 Carriage Bolt 5/16-18 x 1.0” 1
3 710-0451 Carriage Bolt 5/16-18 x 0.750” 1
4 712-04063 Flange Lock Nut, 5/16-18 6
5 720-0284 Chute Knob Assembly 1
6 731-04388A Chute Handle 1
7 731-04426A Upper Chute 1
8 736-0159 Washer 1
9 710-0487 Carriage Bolt 5/16-18 x 2.0 Gr. 1 2
10 720-0284 Handle Knob Assembly 5/16-18 2
11 725-0157 Cable Tie 1
12 736-0451 Saddle Washer .320 x .93 2
13 747-04159 Bail, Gull Wing 1
14 749-04106 Upper Handle, Gull Wing 1
15 684-0178 Mitten Grip Bracket 1
16 684-04029 Shroud Assembly, Black (Incl. Spark Plug Cover) 1
17 710-0895 Screw, 1/4-15 x .75 3
18 710-1003 Self-tapping Screw, #10-16 x .625” 5
19 710-1090 Hex Flange Screw, 5/16-18 x 1.25 2
20 710-1882 Hex Flange Screw 5/16-18 x 1.50 Gr. 5 2
21 710-3083 Hex Screw, 5/16-18 x 1.375 1
22 712-0252 Hex Nut 5/8-32 x .12 Special 1
23 725-2018 Key Switch-Electric Start 1
24 736-0225 Lock Washer Internal .625 x 1.058 1
25 736-0400 Flat Washer .194” x .62” x .063 5
26 736-0451 Saddle Washer .320 x .93 1
27 7510009636 Recoil Handle, Mitten 1
28 710-0134 Screw, 1/4-20 x .62 8
29 710-3008 Truss Machine Screw, 5/16-18 x .75 1
30 712-04064 Hex Flange Lock Nut, 1/4-20 9
31 731-1033 Shave Plate, 19.88 1
32 736-0176 Flat Washer .265 x .938 x .120 4
33 746-04237 Control Cable 1
34 749-04114 Lower Handle 1
35 725-0201 Ignition Key 2
36 684-0189 Spark Plug Cover 1
37 731-04127 Lower Chute 5” Dia. 1
38 731-04353 Ring-Lower Chute 1
39 731-04886 Chute, Adapter 5” Dia 1
40 732-04111 Chute Adjustment Spring 1
41 732-0357A Extension Spring 1
For parts and/or
accessories
please call
1-866-840-6483, or
1-330-558-7220.
www.troybilt.com
Part List:
Snow
Thrower
NOTE:
For painted parts, please
refer to the list of color
codes below. Please add
the applicable color code,
wherever needed, to the
part number to order a
replacement part.
For instance, if a part
numbered 700-xxxx is
painted powder black, the
part number to order would
be 700-xxxx-0637.
Troybilt Red - 0638
Black - 0637
