10 se c t i O n 3 — as s e M b l y & se t -up
The rope guide is attached to the right side of the upper
handle. Loosen the wing knob which secures the rope
a.
Slowly pull starter rope handle from engine and slip b.
Tighten rope guide wing knob.c.
Use cable tie(s) to secure cable(s) to lower handle.d.
Grass Catcher
Follow steps below to assemble the grass catcher (if
needed). Make certain bag is turned right side out before
assembling (warning label will be on the outside).
a.
at the bottom.
Remove the T-bolts from the handle brackets as shown in 2.
Fig. 3-3.
Follow the steps below to complete handle assembly:3.
a.
handle (shown in Fig. 3-3 deck cutaway) line up with
NOTE: When pulling upward on handle, make sure to not
pull handle all the way out.
Insert the T-bolts removed earlier through the b.
handle brackets and lower handle and tighten
Reattach wing nuts and carriage bolts removed c.
earlier into lower holes of handle as shown in Fig.
3-5.
