se c t i O n 3 — as s e M b l y & se t -up
3
2
2
1
3
1
r
Lower
Lower
Handle Pitch
For convenience of operation, you may adjust the pitch of the
handle as follows:
Remove wing nuts and carriage bolts from handle. See Fig.
2.
Secure into position with wing nuts and carriage bolts 3.
removed earlier.
Set-Up
Gas and Oil Fill-Up
engine information.
Add oil provided before starting unit for the first time out
of the box.
Service the engine with gasoline as instructed in the 2.
Use extreme care when handling
gasoline. Gasoline is extremely flammable and the
vapors are explosive. Never fuel the machine
indoors or while the engine is hot or running.
Extinguish cigarettes, cigars, pipes and other
sources of ignition.
Charge battery as instructed in the Service section of this 3.
manual (Electric Start Units).
Adjustments
Cutting Height
There is a cutting height adjustment lever located above the
front and rear right wheel.
tend to fall when lever is moved outward).
Move lever to desired position for a change in cutting 2.
Release lever towards deck.3.
IMPORTANT: Both the front and rear wheels must be
placed in the same relative position. For rough or uneven
lawns, move the height adjustment levers to a higher
position. This will stop scalping of grass.
