16
Specifications
Panel Reader
Size 205 mm x 220 mm x 74 mm (8” x 9.5” x 3”)
Weight 1.1 kg (2½ lb)
Communications interface
RS232, 9600, N, 8, 1, no flow control.
Bluetooth
® wireless interface, class 1 with up to 100 m (300’) range
Operating temperature -15° C to +55° C (5° F to 131° F)
Storage temperature -40° C to +85° C (-40° F to 185° F)
Read range (typical)* HDX - 1 m FDX - 1 m (with Tru-Test Large antenna).
Read rate* HDX - ~850 FDX - ~1000 (max. reads per minute).
Memory capacity Up to 20,000 scanned records
Tag compatibility Reads both ISO HDX and ISO FDX-B.
Supply voltage 12-24 V dc, 7 W, reverse polarity protected
Operating frequency 134.2 kHz ±5 ppm
Antennas
Size 873 mm x 603 mm x 38 mm (2’10½” x 2’ x 1½”) 410 mm x 338 mm x 33 mm (1’4” x 1’2” x 1¼”)
Read range (typical)
Up to 1 m - HDX and FDX
Up to 700 mm – HDX and FDX
2
Actual read range (read distance) depends on the installation (orientation of the tag to the antenna and the influence of electronic noise), the tag manufacturer and
the size of the tag.
