AIS-CTRX Class B AIS Transponder Manual
ANTENNA CONNECTIONS
GPS Antenna
This is a TNC female bulkhead connector mounted under the unit top cover. This port provides the 5V
DC feed for the active GPS antenna required by the AIS-CTRX unit.
VHF antenna
This is a BNC female bulkhead connector mounted under the unit top cover.
Antenna Types and Mounting
Please see Appendix A for antenna details.
