AIS-CTRX Class B AIS Transponder Manual
Fixing Template (NOT TO SCALE)
MOUNTING HOLE
FIXING C ENTRES
TEM PLA TE
M O UN TIN G HO LES I N BA SE PLATE
ARE O 5.5 TO SUIT M5 SCREWS
FRO NT O F UNIT
100,0
160,0
DRAWN
CHECKED
NAME
M.KENDALL
DATE
TI TL E
SI Z E
A4
DWG NO REV
FILE NAME: LD2104-2.dft
SC A LE:
SH EE T 1 OF 1
REVISI O N HISTORY
REV D ESC RI PTI O N D ATE
APPROVED
SO F TWARE RADIO TECHNOLOGY PLC
WESTFIELD INDUSTRI AL ESTATE
MIDSOMER NORTON, BATH, UK. BA3 4BS
UNLESS O THERWISE SPECIFIED
DIMENSIONS ARE IN MILLIMETERS
ANGLES ± 0.5°
0.0 ± 0.2 0.00 ± 0.1
24/2/06
LD2 1 0 4
2
A I S C LA SS B TRANSPONDER
INSTA LLATION TEM PLA TE
1:1
1.1E 39 LD2103
