SAFETY INFORMATION
2222
True Food Service Equipment, Inc.
INSTALLATION / OPERATION INSTRUCTIONS
Removal
A. Opendrawercompletely.Rollerclipswillbeinthedownposition.(seeimage1&2)
B. Whileholdingthesidesofthedrawer,useyourfingertorotatetheclipsupward.(seeimage3)
C. Liftdrawerandremovefromchannel.(seeimage4)
TFP DRAWER REMOVAL AND INSTALLATION
Image 1 Image 3 Image 4
Rotate clip
upward.
Image 2
Installation
A. Lowerrearrollersintochannelslots.(seeimage1)
B. Withtherollerclipsintheupwardposition,lowerfrontrollersintochannel.(seeimage2)
C. Makesurerollerclipsareinthedownposition.
 (seeimage3)
Image 1 Image 3Image 2
