Adjusting Castors for Proper Leveling
Levelunit.Ifunitisnotlevelshimsarerequired.Follow
theseinstructionstoinstallshims.
1. Removefrontandreargrilldependinguponwhichcastor
needsadjusting.Locatethecastorbox.(Seeimage1).
2. Layunitonit’sback.Usesoftpackingmaterialandbe
carefulnottoscratchtheunit.Removepansandlidand
placethemtothesidebeforelayingunitonit’sback.
3. Eachunithasonecastorboxdifferentfromtheothers.
Thisboxistotallyinclosed.Removethiscastorboxfrom
bottomofunit.Backoutfourscrewsanchoringthebox.
Youwillneeda
1
/4”hexheadnutdrivertodisassemble
thiscastorbox.(Seeimage2).
4. Loosencastorwithtoolprovided.(Seeimage3).
5. Installthedesirednumberofshims,makingsuretheslot
oftheshimisincontactwiththethreadedstemofthe
castor.(Seeimage4).Ifmorethanoneshimisused,turn
theslotata90°anglesotheyarenotinline.
6. Afteradjustingcastorreassembleandreinstallcastorbox.
Thencarefullyuprightunitandreinstallpansandlid.
INSTALLATION / OPERATION INSTRUCTIONS
LEVELING AND CASTOR ADJUSTING
TFP MODELS ONLY
1
2
3
4
Locate castor box
One castor box on each unit
is fully enclosed.
Loosen castor.
Install shims.
Castor Box
Anchor
Screws
