Optional
Glass
Doors
All
Trueheat®
fireplaces
are
listed
for
use
with
optional
glass
door
enclosures.
Trueheat®
models
with
the
suffix
letter
G are equipped
with
glass doors factory installed.
(Example:
TH28G)
!?™l,,0s
INSTALLATiON
AND
USE
OF
ANY
OTHER
MANUFACTURERS
GLASS
DOORS
ON
YOUR
TRUEHEAT®
525^*5
E
MAY
CAUSE
A
FIRE
HAZARD
AND
WILL
VOID
THE
TRUEHEAT®
WARRANTY.
DO
NOT
USE
TRUEHEAT®
GLASS
DOORS
ON
ANY
OTHER
FIREPLACE.
When
installing
glass
doors
in
your
Trueheat®
fireplace
follow
the
instructions
provided
with
theglass
doors.
If
your
Trueheat®
fireplace
is
equipped
with
glass
doors
use the
following
instructions
prior
to operation of the
fireplace.
1.) Remove all packaging material from
glass
enclosure
including
wood
supports
in
bottom
of
the
frame.
2.) Move doors to
the
partially
open
position and mount
handles
onto
doors
with
appropriate
screws
and
nuts
(two
per
handle).
CAUTION:
DO NOT OVERTIGHTEN.
See
FIG
17.
Note: When removing glass doors from the glass door frame, depress
spring clips at the top outside corners (See FIG
18)
and allow guide pins
on doors to pop out of clips. Pulltop of doors to the center of the fireplace
and
lift
out
of
clips
on
the
bottom
outside
corners
of
the
doors.
When replacing doors, place bottom door guide pin into hole of door
clip and then slide top door guide pin outward and upwards into upper
door
clip
hole.
For
proper
glass
door
operation
see
your
Trueheat®
Owner's
Manual.
FIG.
17
FRONT
FIG.
18
REMOVING
AND
INSTALLING
GLASS
DOORS
TO
REMOVE:
Push spring
clip
up
(see
arrow)
and
pull
doors
out.
=^SsrJ
TO
INSTALL:
Push
door
guide
pin into spring
clip
hole.
^
SCREW
NUT
STEP
BY
STEP
INSTALLATION:
Use the
step
by
step
instructions
as
a guide for installing your Trueheat® fireplace. It may be
necessary
to alter from the
exact
order
of
these
instructions
depending
on
your
particular
installation.
Step
1: Choose a Location for
the
fireplace. When
selecting
the
location
remember
to
take
into
consideration
the
nearest
available power
source,
outside
air
source
and
gas
source
if you intend to
use
any
of
the
optional
features
available. Also
check
the
ceiling
above
the
desired
location for furnace
ducts,
wiring or plumbing. SEE FIREPLACE
LOCATION
AND FIG. 1.
Step 2. Place the fireplace in the desired location. Ifyou are installing the fireplace in an existing structure, remove any
carpetingor other soft combustible coveringfromthe floorwherethe fireplace is to be installed. Ifthe fireplace is being installed
Page
12
