Page: 12 of 42
8. Attach the throttle cable to the main engine unit as
shown below.
9. Fix the throttle cable on the drive unit and on the handle
using the cable ties.
Attaching the Throttle Cable
Figure 10 The Main Engine Unit
You need:
1. The main engine unit
2. Both cables
3. Screw driver from the
tool kit
Figure 11 The Main Engine Casing
Remove the black casing on
the air filter (located on the
side of the engine) before
installing the throttle cable. It
gives more access to the parts
you need to get to.
