The following parts are required to fit the guard
and line cutter
4 x locking bolts
4 x locking nuts
4 x washers
1 x 4mm Allen key
1 x spanner
• Loosen the metal mounting bracket using
the 4mm Allen key and spanner
• Once loosened, pull the metal bracket away
from the plastic mounting on the pole.
• Place the blade guard up to the mounting
bracket.
• Make sure that the holes on the mounting
bracket and blade guard line-up.
• Insert the locking bolts through the plastic
retaining bracket on the main pole.
