FITTED EQUIPMENT
173
The coupling K-valve is being designed such
that the quick acting valve can only be opened
if the connection is being made via the plug-
in connection. The connection is made by
inserting the plug-in connection into the safety
coupling.
This operation can be carried out using one
hand. After uncoupling the equipment, seal off
the valve opening using the protection seal.
Note: The external gas socket is only
suitable for removing gas, not for feeding
gas into the gas system.
! WARNING: Care should be taken when
using the external barbeque point. Never
barbeque next to an awning or tent.
! WARNING: The caravan barbeque point
should only be used as an outlet point for
gas, never connect a gas bottle direct to the
outlet.
External shower point
The external shower point, if fitted, will be
supplied with a separate shower head and
hose assembly. To connect the shower,
simply align the plug with the socket and
push into position. To remove, pull the lower
trigger and pull the plug from the socket.
Caravans with TV inlet in
battery box
Models equipped with TV points in the battery
box have the facility to take an external signal
and supply that signal to TV points within the
caravan.
Caravans equipped in this way feature a direct
link from the connection point in the battery
box, to an auxiliary connection point at the
primary TV position within the caravan. The
primary TV position is that which also features
an AV outlet plate (see later text).
EXTERNAL SHOWER POINT /
BATTERY BOX
