trutankless TR15 - T Ec Hnical Data

INSTALLATION AND OPERATION GUIDE
13
ELECTRICAL DATA INLET WATER DATA
MECHANICAL DATA
SPECIFICATIONS
TECHNICAL DATA
Voltage
Phase
Wattage
Max. Amp, Load
Min. Circuit Breaker Size
Required Wire Size
208 - 240 VAC
Single, 50/60 Hz
12.5 - 36.0 kW
40A x 4=160A
(See Table)
(See Table)
Max. Inlet Temperature °F (°C)
Water Flow to Activate Unit = GPM (=LPM)
Max. GPM = GPM (= LPM)
Max. Working Pressure PSI (bar)
Tested to Pressure PSI (bar)
131 (55)
0.2 (.76)
7.5 (28)
80 (5.5)
150 (10.34)
Residential Weight lbs. (kg)
Commercial Weight lbs. (kg)
Dimensions HxWxD inches (cm)
35.3 (16)
35.9 (16.3)
17.3 x 23.74 x 5.5 (44.1 x 60.3 x 14)
Model Height Width Depth Weight Amperage
Voltage
Range
kW Range
Main Panel
Size
Breakers
(two pole)
Copper Wire
[optional]
Plumbing
Fittings
TR36
17.3" 23.74" 5.5" 35.3 lbs
160
220 - 240 31.8 - 36.0 > 200 A (2) 80A (4) #4 AWG
Threaded
3/4" NPT
TR29
17.3” 23.74" 5.5" 35.3 lbs 120 220 - 240 26.4 - 28.8 200A
(1) 125A
[(2) 60A]
(2) #2 AWG
[(4) #6 AWG)]
Threaded
3/4" NPT
TR24
17.3" 23.74" 5.5" 35.3 lbs 100 220 - 240 22.0 - 24.0 200A
(1) 100A
[(2) 50A]
(2) #2 AWG
[(4) #6 AWG]
Threaded
3/4" NPT
TR20
17.3" 23.74" 5.5" 35.3 lbs 80 220 - 240 17.6 - 19.2 150A
(1) 80A
[(2) 40A]
(2) #4 AWG
[(4) #8 AWG]
Threaded
3/4" NPT
TR15
17.3" 23.74" 5.5" 35.3 lbs
60
220 - 240 13.2 - 14.4 125A
(1) 60A
[(2) 30A]
(2) #6 AWG
[(4) #8 AWG]
Threaded
3/4" NPT
Model Height Width Depth Weight Amperage
Voltage
Range
kW Range
Main Panel
Size
Breakers
(two pole)
Copper Wire
[optional]
Plumbing
Fittings
TC33
17.3" 23.74" 5.5" 35.9 lbs
160
208 33.3 > 200A (2) 80A (4) #4 AWG
Threaded
3/4" NPT
TC25
17.3" 23.74" 5.5" 35.9 lbs 120 208 25.0 200A
(1) 125A
[(2) 60A]
(2) #2 AWG
[(4) #6 AWG)]
Threaded
3/4" NPT
TC21
17.3" 23.74" 5.5" 35.9 lbs 100 208 20.8 200A
(1) 100 A
[(2) 50A]
(2) #2 AWG
[(4) #6 AWG]
Threaded
3/4" NPT
TC17
17.3" 23.74" 5.5" 35.9 lbs 80 208 16.6 150A
(1) 80A
[(2) 40A]
(2) #4 AWG
[(4) #8 AWG]
Threaded
3/4" NPT
TC13
17.3" 23.74" 5.5" 35.9 lbs
60
208 12.5 125A
(1) 60A
[(2) 30A]
(2) #6 AWG
[(4) #8 AWG]
Threaded
3/4" NPT
NOTE: Tankless water heaters are considered a non-continuous load
NOTE: Conductors should be sized to maintain a voltage drop of less than 3% under load
NOTE: American Wire Gauge (AWG) Tables are available at http://en.wikipedia.org/wiki/American_wire_gauge#Tables_of_AWG_wire_sizes
